Background

Not to be confused with the more expensive iPhone 11 Pro and Pro Max, the standard iPhone 11 is Apple’s mainstream smartphone starting at $699 USD. It was released in 2019 and came with a slightly larger screen than the iPhone X and XS.

The most often replaced iPhone 11 parts include the battery, screen, antennas and lightning connector assembly.

Identification

You can identify the iPhone 11 by finding one of the model numbers either on the inner edge of the SIM card tray or within the phone's Settings app:

  • A2111
  • A2221
  • A2223

You can find the model number through the phone's UI by going to the Settings app and navigating to General > About. Tap on the number listed in the Model Number section and it should change to a format that looks like the numbers above.

The iPhone 11 features a 6.1 in (diagonal) glass screen with curved edges, thin black bezels, and a notch at the top of the screen to accommodate a speaker and selfie camera. The back cover is glass and the edge frame is made from curved and anodized aluminum.

Volume controls can be found on the left edge while the power button and SIM card tray are situated on the right. A rectangular camera "bump" containing two vertically-aligned cameras protrudes slightly from the back case. This model has no home button.

The iPhone 11 can be differentiated from the iPhone 12 by the 11's curved edges relative to the flat edges on the iPhone 12.

Specifications

Announce date: September 10, 2019

Operating System: iOS 13

Display:

  • 6.1-inch “Liquid Retina” LCD
  • Multi‑touch display with IPS technology
  • 1792‑by‑828‑pixel resolution at 326 ppi
  • 1400:1 contrast ratio (typical)
  • True Tone
  • P3 wide color gamut
  • 625 nits max brightness (typical)
  • Fingerprint-resistant oleophobic coating

Dual primary camera:

  • True Tone flash
  • 4K video recording, up to 60 fps
  • Wide-angle module
    • 12 MP
    • ƒ/1.8 aperture
    • Optical image stabilization (OIS)
    • Autofocus with 100% Focus Pixels
    • Six-element lens
  • Ultra-wide module (120° field of view)
    • 12 MP
    • ƒ/2.4 aperture
    • Five-element lens

TrueDepth selfie camera with Face ID:

  • 12 MP
  • ƒ/2.2 aperture
  • 4K video recording, up to 60 fps
  • Retina Flash

Processor: A13 Bionic with 3rd-generation Neural Engine

  • 7 nm process
  • 6 cores

RAM: 4 GB

Storage: 64, 128, or 256 GB

Sensors:

  • Face ID
  • Barometer
  • Three-axis gyro
  • Accelerometer
  • Proximity sensor
  • Ambient light sensor

Wireless Connectivity:

  • 802.11ax Wi‑Fi 6 with 2x2 MIMO
  • Gigabit-class LTE with 2x2 MIMO and LAA
  • Bluetooth 5.0 wireless technology
  • Apple-designed U1 Ultra Wideband chip for spatial awareness
  • NFC

Dimensions: 5.94 × 2.98 × 0.33 in (150.9 × 75.7 × 8.3 mm)

Weight: 194 g (6.84 oz)

Colors: Black, Green, Yellow, Purple, (PRODUCT) RED, White
